Belt conveyor with large throughput, simple structure, convenient maintenance and standardization of components, it is widely used in mining, metallurgical, coal and other departments, used to transport loose materials or items, according to the conveying process requirement, can be a single delivery, or can be more With other conveying equipment to form horizontal or inclined conveyor system, in order to satisfy different arrangement type of line. Suitable for conveying bulk density is less than 1.67 / ton/m3, Easy to take out the powder, granular, small block of low grinding cut materials, or packaged materials, such as coal, gravel,Sand, cement, fertilizer, food, etc. Sent material temperature is less than 60 ℃. The captain and assembly form according to customers' requirement, the transmission can use electric drum, also can use tape drive rack driving devices. Belt conveyor is a complete set of crushing screening equipment indispensable equipment.
Belt width
(mm) |
Conveying length (m)
Power(kw) |
Conveyor speed (m/s)
|
Throughput(t/h)
|
||
500
|
≤12
3 |
12-20
4-5.5 |
20-30
5.5-7.5 |
1.3-1.6
|
78-191
|
650
|
≤12
4 |
12-20
5.5 |
20-30
7.5-11 |
1.3-1.6
|
131-323
|
800
|
≤6
4 |
6-15
5.5 |
15-30
7.5-15 |
1.3-1.6
|
278-546
|
1000
|
≤10
5.5 |
10-20
7.5-11 |
20-40
11-22 |
1.3-2.0
|
435-853
|
1200
|
≤10
7.5 |
10-20
11 |
20-40
15-30 |
1.3-2.0
|
655-1284
|
