Dual-axis mixer using two symmetrical shaped screw axis synchronous rotation, such as transportation of dry ash mixing of powder material at the same time, adding water, add wet dry ash powder material, to add wet material not risked dry ash and not the purpose of the seepage water droplets, thereby facilitating humidifying dust loading transportation or transferred to other devices. Mainly suitable for thermal power plants, mining and other industries humidifying loading situation of fly ash or similar material.
Type/SJJ |
Capacity (m3/h) |
The effective length of mixing(mm) |
Stirring speed of the mixing axle (r/min) |
Power (kw) |
Weight (kg) |
3000×312 | 25~40 | 2400 | 42~48 | 30~37 | 2200 |
3500×360 | 35~60 | 2800 | 36~42 | 37~45 | 3860 |
4000×400 | 45~80 | 3300 | 30~36 | 45~55 | 5330 |
4500×420 | 55~100 | 3800 | 24~30 | 55~75 | 7476 |
5000×450 | 80~140 | 4200 | 18~24 | 75~90 | 11060 |
3500×360 | 35~60 | 2800 | 36~42 | 37~45 | 3860 |
4000×400 | 45~80 | 3300 | 30~36 | 45~55 | 5330 |
4500×420 | 55~100 | 3800 | 24~30 | 55~75 | 7476 |
5000×450 | 80~140 | 4200 | 18~24 | 75~90 | 11060 |
