Jaw crusher works for dynamic JiYaXing, its working principle is: motor drive belt and pulley, make through eccentric shaft dynamic jaw movement up and down, when moving jaw rises between the bracket and fixed jaw Angle, so as to promote dynamic jaw plate to the fixed jaw close, rather than the material being crushed or broken at the same time, achieve the purpose of broken; When the moving jaw downward, bracket and dynamic jaw Angle smaller, moving jaw in the bar, under the action of the spring, leave the fixed jaw plate, now broken material from crushing cavity mouth eduction.As the motor turns continuously and broken mobile jaw crushing and discharge material for periodic motion, to realize batch production.
model
|
Inlet size
(mm) |
The largest feed particle size
(mm) |
The discharging mouth adjusting range
(mm) |
Processing power
(t/h) |
The eccentric shaft speed
(r/min) |
power
(kw) |
The weight of the
(t) |
Overall dimensions
(mm) |
PE-150×250
|
150×250
|
130
|
10-40
|
1-5
|
300
|
5.5
|
0.9
|
875×756×850
|
PE-250×400
|
250×400
|
210
|
20-80
|
5-21
|
300
|
15
|
2.6
|
1450×1315×1296
|
PE-400×600
|
400×600
|
350
|
40-100
|
16-65
|
275
|
30/37
|
6.5
|
1565×1732×1586
|
PE-500×750
|
500×750
|
425
|
50-100
|
45-100
|
275
|
55
|
10.1
|
1890×1916×1870
|
PE-600×900
|
600×900
|
500
|
65-160
|
90-180
|
250
|
55/57
|
15.5
|
2305×1840×2260
|
PE-750×1060
|
750×1060
|
630
|
80-140
|
110-320
|
250
|
110
|
28
|
2450×2472×2840
|
PE-800×1060
|
800×1060
|
650
|
100-200
|
140-350
|
250
|
110
|
28.5
|
2450×2556×2800
|
PE-870×1060
|
870×1060
|
670
|
200-260
|
140-380
|
250
|
110
|
30.5
|
2660×2556×2800
|
PE-900×1200
|
900×1200
|
750
|
100-200
|
180-360
|
250
|
132
|
50
|
3335×3182×3025
|
PE-1000×1200
|
1000×1200
|
850
|
192-260
|
200-420
|
250
|
132
|
51
|
3435×3182×3025
|
PE-1200×1300
|
1200×1300
|
1000
|
180-330
|
400-800
|
220
|
200
|
62
|
4538×2984×3959
|
PE-1200×1500
|
1200×1500
|
1020
|
150-350
|
400-800
|
180
|
220
|
100.9
|
4200×3732×3025
|
PE-1500×1800
|
1500×1800
|
1200
|
220-350
|
450-1000
|
180
|
280
|
122
|
5100×4700×4300
|
PEX-250×1000
|
250×1000
|
210
|
25-60
|
16-52
|
330
|
30/37
|
6.5
|
1530×1992×1380
|
PEX-250×1200
|
250×1200
|
210
|
25-60
|
20-60
|
330
|
37
|
7.7
|
1900×2192×1430
|
PEX-300×1300
|
300×1300
|
250
|
25-90
|
20-90
|
330
|
55
|
11
|
1900×2192×1430
|
