1. PLD series concrete batching machine is a kind of automatic foreground batching machine matched with the mixer. It can automatically finish the batching procedures of 3~6 kinds of materials(second grade concrete) such as sand, stone, cement according to users′ design.
2. This series concrete batching machine adopt electronic weighing, computer control, digital display, cable remote control, which has the advantages of accurate weighing, high batching precision, powerful controlling function and easy operation, etc.
3. This series concrete batching machine can combine with the related concrete mixer to form combined concrete batching plant of different types and different specifications.
Application
PL Series concrete batching machine is a kind of automatic batching equipment equipped with the mixer. It can finish automatically the batching process of sand, stone, cement etc. 3~6 kinds of material according to the cement proportion designed by user. It can batch materials to one or two mixer, so it greatly improves the working efficiency.
Product features
1. High weighing accuracy
2. High precision ingredients
3. High speed
4. Strong control function
5. Easy to control
6. Spare parts available
| PLD series concrete batching machine-Technical parameter | ||||||||
| Model | PLD600 | PLD800 | PLD1200A | PLD1200B | PLD1600 | PLD2400 | PLD3200 | PLD4800 |
| Cubage of weighing hopper (L) | 600 | 800 | 1200 | 1200 | 1600 | 2400 | 3200 | 4800 |
|
Cubage of storaging Hooper(m 3 ) |
2 × 1.2 | 2 × 2 | 2 × 3 | 3 × 3 | 4 × 5 | 4 × 10 | 4 × 18 | 4 × 25 |
| Productivity(m 3 /h) | 30 | 48 | 60 | 60 | 75 | 120 | 180 | 280 |
| Batching accuracy (%) | ± 2% | ± 2% | ± 2% | ± 2% | ± 2% | ± 2% | ± 2% | ± 2% |
| Max.weighingvalue(kg) | 2000 | 2000 | 3000 | 3000 | 3000 | 4000 | 5000 | 8000 |
|
Number of available aggregates |
2-3 | 2-3 | 2-4 | 2-4 | 2-5 | 2-5 | 2-5 | 2-6 |
| Feeding height(m) | 1850 | 2430 | 2600 | 2600 | 2900 | 2900 | 2300 | 2300 |
| Belt speed (m/s) | 1.25 | 1.25 | 1.25 | 1.25 | 1.25 | 1.25 | 1.25 | 1.25 |
| Total weight(kg) | 1360 | 2300 | 2800 | 4100 | 5600 | 8500 | 10500 | 14000 |
| Outer machine(mm) |
3800* 1400* 2200 |
5400* 1800* 3010 |
6000* 1800* 3090 |
8400* 1800* 3100 |
12000* 2200* 4000 |
10000* 2200* 4000 |
14500* 3000* 4600 |
15520* 3900* 5090 |
