Product Introduction:
Main technical Specifications :
Oriented column: made of special steel, chrome plated , and can bear powerful suppress and wears well..
Mold head: synchronize with mechanic, electricity and hydraulic. Products made by the same pallet are within narrow degree of errors..
Feeding: Sensor and hydraulic are droved synchronically in proportion, the force to swing material and arch-breaking generates strong centrifugal power to feed materials, which results in rapid feeding and particularly good for thin-walled products with multi-holes.
Vibration: Hydraulic drive and multi-source vibration system, the computer-controlled hydraulic drive generated vertical synchronization. Adjustable frequency makes it possible to feeding in low-frequency. High frequency operation guarantees good effects of different raw materials and the vibration acceleration is up to 17.5.
Control system: Computer control, HMI, electric parts uses brands like Mitsubishi. With experienced production actions, design philosophy integrated international and Chinese trends. To operate it requires small training and no experts. Its strong memory makes it possible to be upgraded.
Store and distribute materials devices: the computer-controlled material supply avoids suppressing materials, and ensures well-distributed feeding and stable and well product intensity.
Raw Materials
crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, perlite, and other industrial wastes.
Applied Products
concrete blocks, solid/hollow/cellular masonry products, paving stones with or without face mix, garden and landscaping products, slabs, edgers, kerbstones, grass blocks, slope blocks, interlocking blocks, etc.
Applied Fields
widely used in buildings, road pavers, squares, gardens, landscaping, city constructions, etc.
Specification
| QT12-15 | Product model | Product size | Pcs /mould | Forming cycle | Capacity/8h | |||||
| Hollow brick | 390x190x190mm | 12 | 15 | 23040 pcs | ||||||
| Porous brick | 240x115x90mm | 30 | 15 | 57600 pcs | ||||||
| Standard brick | 240x115x53mm | 60 | 15 | 115200 pcs | ||||||
|
Main motor: 40kw |
Carriage plate size: 900x1300x40mm |
Host machine weight: 14.5T | ||||||||
| QT10-15 | Product model | Product size | Pcs /mould | Forming cycle | Capacity/8h | |||||
| Hollow brick | 390x190x190mm | 10 | 12-15 | 19200 pcs | ||||||
| Porous brick | 240x115x90mm | 24 | 12-15 | 57600 pcs | ||||||
| Standard brick | 240x115x53mm | 52 | 12-15 | 124800 pcs | ||||||
|
Main motor: 40kw |
Carriage plate size: 1090x870x35mm |
Host machine weight: 13.2T | ||||||||
| QT8-15(A) | Product model | Product size | Pcs /mould | Forming cycle | Capacity/8h | |||||
| Hollow brick | 390x190x190mm | 8 | 12-15 | 15360pcs | ||||||
| Porous brick | 240x115x90mm | 21 | 12-15 | 50400 pcs | ||||||
| Standard brick | 240x115x53mm | 42 | 12-15 | 100800 pcs | ||||||
|
Main motor: 32kw |
Carriage plate size: 980x840x30mm |
Host machine weight: 11.8T | ||||||||
| QT8-15(B) | Product model | Product size | Pcs /mould | Forming cycle | Capacity/8h | |||||
| Hollow brick | 390x190x190mm | 8 | 12-15 | 15360 pcs | ||||||
| Porous brick | 240x115x90mm | 18 | 12-15 | 43200 pcs | ||||||
| Standard brick | 240x115x53mm | 36 | 12-15 | 86400 pcs | ||||||
|
Main motor: 32kw |
Carriage plate size: 850x850x30mm |
Host machine weight: 9.8T | ||||||||
| QT6-15 | Product model | Product size | Pcs /mould | Forming cycle | Capacity/8h | |||||
| Hollow brick | 390x190x190mm | 6 | 12-15 | 12400 pcs | ||||||
| Porous brick | 240x115x90mm | 15 | 12-15 | 36000 pcs | ||||||
| Standard brick | 240x115x53mm | 30 | 12-15 | 72000 pcs | ||||||
|
Main motor: 32kw |
Carriage plate size: 850x680x30mm |
Host machine weight: 8.8T | ||||||||
| QT6-20 | Product model | Product size | Pcs /mould | Forming cycle | Capacity/8h | |||||
| Hollow brick | 390x190x190mm | 6 | 15-20 | 11520 pcs | ||||||
| Porous brick | 240x115x90mm | 15 | 15-20 | 28800 pcs | ||||||
| Standard brick | 240x115x53mm | 30 | 15-20 | 57600 pcs | ||||||
|
Main motor: 29kw |
Carriage plate size: 780x890x30mm |
Host machine weight: 9.5T | ||||||||
| QT4-25 | Product model | Product size | Pcs /mould | Forming cycle | Capacity/8h | |||||
| Hollow brick | 390x190x190mm | 4 | 24-26 | 5800pcs | ||||||
| Porous brick | 240x115x90mm | 9 | 24-26 | 14000 pcs | ||||||
| Standard brick | 240x115x53mm | 21 | 24-26 | 33000 pcs | ||||||
|
Main motor: 16.58kw |
Carriage plate size: 850x480x40mm |
Host machine weight: 5T | ||||||||
|
QRT4-40 (mannual) |
Product model | Product size | Pcs /mould | Forming cycle | Capacity/8h | |||||
| Hollow brick | 390x190x190mm | 4 | 40 | 2800 pcs | ||||||
| Porous brick | 240x115x90mm | 9 | 40 | 6480 pcs | ||||||
| Standard brick | 240x115x53mm | 21 | 40 | 15120 pcs | ||||||
|
Main motor: 9.6kw |
Carriage plate size: 850x550x40mm |
Host machine weight: 1.5T | ||||||||
1.aera:work aera 150-200m2,factory aera 4000-6000m2.
2.worker quantity: 3-5 workers
3.cement:sand:small stone: about 1:4:5
4.brick weight:hollow 400*200*200mm---7.5kg,solid 240*115*53mm---3.5kg and porous 240*115*90mm---4.5kg
4.QT8-15 automatic brick making machine price comes with belt conveyor and one set of brick mould,and we can produce the brick mould according to the design of brick which sell well in your aera.
5.If every spare part of QT8-15 automatic cement brick making machine is broken in one year,we'll change for free,and we can free guidance in lifetime.
6.After you confirm our QT8-15 automatic cement brick making machine(with good price),pls tell me the electricity details in your local,how many volts?220v,380v or others?and one phase or three phases?50Hz or 60Hz?so that we install the motors according to your electricity and make sure brick making machine works well when you use it.
7.Production time and delivery time:25-30days for production,and in 35 days we'll delivery the brick machine.
8.About the shipment:we have good shipping company with long-term cooperative relationship,so they can ship QT8-15 automatic cement brick making machine with good price and service for you.
